CARBURETTOR
Tickover adjustment
Tickover adjustment has a major influence
on starting the engine. That is to say, an en-
gine with a correctly adjusted tickover will
be easier to start than an engine with incor-
rect tickover adjustment.
You adjust the tickover using the adjuster
knob (A), which regulates the base position
of the throttle valve.
Throttle free clearance adjustment
To adjust the tension of the throttle cable,
use adjuster B. If this amount of adjustment
is insufficient, use adjuster C (on the throt-
tle cable itself).
CHECKING AND ADJUSTING STEERING
CLEARANCE
Check the steering head tube clearance
on a periodic basis, moving the forks back-
wards and forwards as shown in the figure.
If a clearance is felt, adjust as follows:
- Remove the handlebar protection.
- Unscrew the two screws (C).
- Remove handlebar D.
- Loosen nut E.
A
B
C
