WARTUNG UND KONTROLLEN
192
3
A
B
Ausbau hinterer Kotflügel
Der hintere Kotflügel besteht aus
zwei Teilen. Oben ein farbiges und
unteren ein schwarzes Plastikteil.
Zum Abmontieren des oberen Teils
zunächst die hinteren Seitenverklei-
dungen abbauen und dann die
Befestigungsschraube A entfernen.
Zum Abmontieren des unteren Teils
die 3 Befestigungsschrauben B un-
ter dem Kotflügel abschrauben.
