Beverage-Air PH - Clearance and Placement

User Manual for PH Warming Cabinets Beverage-Air
Rev. 01/21Beverage-Air6
CLEARANCE AND PLACEMENT
Placement
Consider the following when selecting a location for your Cabinet:
Clearance:
• 10 in. at the top
• 0.0 in. at the rear,
• 0.0 in. at the left side
• 0.0 in. at the right side
• 0.0 in at the bottom
Floor Load: the oor on which the Cabinet is located must be even and level, free from vibrations, and strong enough to
support the combined weights of the unit and maximum product load.
Ventilation: Grille area at front must be free and clear of any object or wall.
Power Outlet: The installation of this appliance requires a dedicated power outlet located within the length of the unit's
power cord and be accessible for the purpose to disconnect power.
0"
REAR
MINIMUM
CLEARANCE
10" TOP
MINIMUM
CLEARANCE
MINIMUM
BOTTOM
CLEARANCE
0"
0"
LEFT/RIGHT
MINIMUM
CLEARANCE
