BFT ARGO BT A 35 - Page 22

ENGLISH
TABLE “A”  PARAMETERS MENU - PARA 
Parameter min. max. Default Personal Denition Description
TCA
0 180 40
Automatic closing
time [s]
Waiting time before automatic closing.
t.light
30 300 90
Lighting time of the
courtesy light [s]
Lighting time of the courtesy light [s] Activation time of the courtesy light on the board
output
ti
e
1 240 10
Activation time of
the timed output [s]
Activation length of timed radio channel output in seconds
OP.DIST.
SLOUD
7 99 7
Slow-down distance
during opening [%]
Slow-down distance for motor(s) during opening, given as a percentage of total travel. WARNING: Once
the parameter has been edited, a complete uninterrupted opening-closing cycle is required.
WARNING: when the display reads “SET”, obstacle detection is not active.
CL.DIST.
SLOUD
7 99 7
Slow-down distance
during closing [%]
Slow-down distance for motor(s) during closing, given as a percentage of total travel. WARNING: Once
the parameter has been edited, a complete uninterrupted opening-closing cycle is required.
WARNING: when the display reads “SET”, obstacle detection is not active.
PARTIAL
OPENING
10 99 20 Partial opening [%]
Partial opening distance as a percentage of total opening following activation of PED pedestrian
command.
out prog 1
1 99 50
Output 1, pro-
grammable
in height
The output set as AUX=17 (see the AUX outputs Conguration table) gets activated when the
door exceeds the opening percentage set in this parameter (1% = door closed, 99% = door open).
out prog 2
1 99 50
Output 2, pro-
grammable
in height
The output set as AUX=18 (see the AUX outputs Conguration table) gets activated when the
door exceeds the opening percentage set in this parameter (1% = door closed, 99% = door open).
OP.FORCE
1 99 75
Leaf force during
opening [%]
Force exerted by leaf/leaves during opening. This is the percentage of force delivered, beyond
the force stored during the autoset cycle (and subsequently updated), before an obstacle alarm
is generated.
The parameter is set automatically by the autoset function.
WARNING: It aects impact force directly: make sure that current safety requirements
are met with the set value (*). Install anti-crush safety devices where necessary (**).
CLS.FORCE
1 99 75
Leaf force during
closing [%]
Force exerted by leaf/leaves during closing. This is the percentage of force delivered, beyond the
force stored during the autoset cycle (and subsequently updated), before an obstacle alarm is
generated.
The parameter is set automatically by the autoset function.
WARNING: It aects impact force directly: make sure that current safety requirements
are met with the set value (*). Install anti-crush safety devices where necessary (**).
rev.dis.
space
0 200 0
Reverse
disabling space
Disables obstacle/curb detection near the limit stop in closing
0 = no disabling 200 = disabling Maximum
WARNING: It aects impact force directly: make sure that current safety requirements
are met with the set value (*). Install anti-crush safety devices where necessary.
OP SPEED
25 99 99 Opening speed [%}
Percentage of maximum speed that can be reached by motor(s) during opening. WARNING: Once
the parameter has been edited, a complete uninterrupted opening-closing cycle is required.
WARNING: when the display reads "SET", obstacle detection is not active.
CL SPEED
25 99 45 Closing speed [%]
Percentage of maximum speed that can be reached by motor(s) during closing. WARNING: Once
the parameter has been edited, a complete uninterrupted opening-closing cycle is required.
WARNING: when the display reads "SET", obstacle detection is not active.
ainte-
nance
0 250 0
Programming num-
ber of operations
for maintenance
threshold
[in hundreds]
Allows you to set a number of operations after which the need for maintenance will be reported
on the AUX output congured as Maintenance or Flashing Light and Maintenance .
(*) In the European Union, apply standard EN 12453 for force limitations, and standard EN 12445 for measuring method.
(**) Impact forces can be reduced by using deformable edges.
TABLE “B”  LOGIC MENU - logic
Logic Denition Default
Cross
out
setting
used
Optional extras
TCA
Automatic
Closing Time
0
0 Logic not enabled
1 Switches automatic closing on
STEP-BY-STEP
OVE NT
Step-by-step
movement
0
0
Inputs congured as Start E, Start I, Ped oper-
ate with 4-step logic.
step-by-step mov.
3 STEP 4 STEP
CLOSED
OPENS
OPENS
DURING CLOSING STOPS
OPEN
CLOSES CLOSES
DURING OPENING
STOP + TCA STOP + TCA
AFTER STOP OPENS OPENS
1
Inputs congured as Start E, Start I, Ped oper-
ate with 3-step logic. Pulse during closing
reverses movement.
sw ov
Movement on
endstop
3
0 Logic not active
1-10
Causes the movement to be reversed when it stops on the closing limit switch
(10 = Greater movement)
PRE-ALAR
Pre-alarm 0
0 The ashing light comes on at the same time as the motor(s) start.
1 The ashing light comes on approx. 3 seconds before the motor(s) start.
22-ARGO BT A 20-35
D814038 0AA00_03
