INTRODUCTION COMFORT CIRCLE
8
If some part of the manual applies to certain models only,
these will be indicated using the corresponding type refer
-
ence, for instance:
•CC M: units with modulating control;
•CC S: units with simple control;
•CC V: ventilation units;
•CC V-H: ventilation unit with horizontal connection.
Not all combinations are possible.
1.3.4 Type plate
The type plate can be found on the front side of the unit.
This manual refers to the following data on the type plate:
• Type: full type code of the unit;
• M: weight of the unit;
• p
max
: maximum permissible operating pressure in the hot
water circuit (at 110
ºC);
• U, I
max
, P
motor
and P
heating
: the unit’s maximum load on the
electrical system.
Table 1-2 Type code explained
TYPE CODE ELEMENT REFERENCE MEANING
product series Comfort Circle general reference for the Comfort Circle
physical size 60 or 90 dimensions of the unit in the ceiling, 600x600mm and
900x900mm
ventilation V no reference: recirculation unit, V = ventilation unit
heat exchanger H2, H3 water-heated, 2 or 3 rows
C2, C3 water-cooled, 2 or 3 rows
H1/C2 water-heated and -cooled, 1 and 2 rows, resp.
control M modulating control
S On/Off control
discharge angle adjust-
ment
0 or 1 without or with automatic angle adjustment
ventilation connection H or V horizontal (CC V-H) or vertical (CC V-V) ventilation
connection
Type CC 60-H2-M1
Code U 230 V 1N~ 50 Hz
Biddle bv
Markowei 4
NL-9288 HA Kootstertille
Nº 123456/1-1 05-53 I
max
L1 xxx A
I
max
L2 -
M30kg I
max
L3 -
Medium LPHW P
motor
xxx kW
p
max
1400 kPa P
heating
-
xxx
