• If trailer is equipped with electronic control system, supply voltage must be observed
according to trailer options.
HANDLING IN ROLL ON - ROLL OFF
Exchange and tipping must be operated from the operator’s seat in the towing
vehicle!
If your BIGAB is equipped with suspension there is no bogie blocking.
Ensure that the trailer is straight in
front of the load!
Ensure that the position
selector for exchange or
tipping is in the exchange
position, not in the tipping
position!
On-loading!
• Check that the load carrier is within the discs. Release the brakes on both the towing vehicle
and the trailer to make it easier to roll on the load. Check the position of the tower during on-
loading, so that the container frame does not catch on to the rollers from behind.
• The tower must be completely retracted when rolling on the container bridge in order to increase
lifting force and reduce the strain on the coupling device. Ensure that the container frame does
not catch in the rollers at the back of the trailer. Adjust the tower outwards continually during
exchange in order to move clear past the rollers. If the tower is not adjusted upwards during
on-loading, there is a considerable risk of the exchange’s lock being damaged if the container
frame catches in the rollers.
Stop if the tractor lifts o the ground!
Check that the hook
catches around the loop!
Check that the frame lock
and bogie blocking are
activated!
