Rear lights
The trailer is manufactured with 12V electrical system.
Rear light electrical scheme
Table 8. Rear light electrical scheme main components
Pos
Description Qty.
1
Cable set with plug 1
2
Right rear lights 1
3
Left rear lights 1
4
Connection box 1
5
Terminal strips 10mm2 1
6
Ferrule 10
