Steerable drawbar BIGAB 8-12– 14-17
Table 15. Steerable drawbar 8-12 – 14-17
Pos Description Pos Description
1
Angle nipple 6 H-hose
2 Rubber seal 7 H-hose
3 Bayonet coupling 8 Heat shrink tube
4 Dust cover 9 Sticker
5 H-hose
Hydraulic scheme.Steerable drawbar 8-12 – 14-17
