Sengs page includes six submenus: EDID Sengs, CEC Control, Login Username, Login
Password, Network and Firmware Version.
1. EDID Sengs
This secon allows the EDIDs to be congured for each output based on the requirements of
the displays in the system based on the available EDID seng below.
 
SmartEDID (Default)
Reviews the resoluons of all connected displays
and sets the EDID to the lowest resoluon and/or
audio available for all outputs.
EDID Write
Copies the EDID from the display connected to the
selected output.
Fixed 4K60 7.1CH Encoded Audio with
HDR
Supports up to: 4K60 7.1CH with HDR
Fixed 4K30 2.0CH PCM Audio with
SDR
Supports up to: 4K30 2.0CH PCM with SDR
Fixed 1080p@60Hz 7.1CH Encoded
Audio with HDR
Supports up to: 1080p@60Hz 7.1CH with HDR
Fixed 1080p@60Hz 5.1CH Encoded
Audio with HDR
Supports up to: 1080p@60Hz 5.1CH with HDR
Fixed 1080p@60Hz 2.0CH Audio with
HDR
Supports up to: 1080p@60Hz 2.0CH with HDR
Fixed 1080p@60Hz 2.0CH Audio with
SDR
Supports up to: 1080p@60Hz 2.0CH with SDR
Conguring EDIDs
1. Select the Output port (HDMI 1-4) from Output drop-down menu.
2. Select the EDID seng for each input based on the above table.
Note: If EDID copy fails the output will default to 4K@30Hz 2.0ch audio.
