2.1 B 28 chamber overview
Figure 3: Incubator B 28
(1) Control thermometer
(4) Thermostat
(2) Main power switch (5) Pilot lamp yellow (heating active)
(3) Pilot lamp green (ready to operate)
(6) Thermostat brake
2.2 E 28 chamber overview
Figure 4: Drying and heating oven E 28
(1) Control thermometer
(2) Timer 0-120 minutes (also main power switch)
(3) Pilot lamp green (ready to operate)
(4) Thermostat
(5) Pilot lamp yellow (heating active)
(6) Thermostat brake
