12.4 BD technical data
Chamber size
BD 23
BD 53
BD 115
BD 240
BD 400
BD 720
Exterior dimensions
Width, net
mm
inch
435
17.13
635
25.00
835
32.87
1035
40.75
1235
48.62
1235
48.62
Height, gross (incl. feet/castors)
mm
inch
495
19.49
620
24.41
705
27.76
825
32.48
1025
40.35
1530
60.24
Depth
mm
inch
520
20.47
575
22.64
645
25.39
745
29.33
765
30.12
865
34.06
Depth, gross (incl. door handle and
exhaust duct)
mm
inch
625
24.61
680
26.77
750
29.53
850
33.46
870
34.25
970
38.19
Wall clearance rear (minimum)
mm
inch
100
3.94
100
3.94
100
3.94
100
3.94
100
3.94
100
3.94
Wall clearance side (minimum)
mm
inch
100
3.94
160
6.30
160
6.30
160
6.30
160
6.30
160
6.30
Exhaust duct, outer diameter
mm
inch
52
2.05
52
2.05
52
2.05
52
2.05
52
2.05
52
2.05
Doors
Number of doors
1
1
1
2
2
2
Interior dimensions
Width
mm
inch
222
8.74
400
15.75
600
23.62
800
31.50
1000
39.37
1000
39.37
Height
mm
inch
330
12.99
400
15.75
480
18.90
600
23.62
800
31.50
1200
47.24
Depth
mm
inch
277
10.91
330
12.99
400
15.75
500
19.69
500
19.69
600
23.62
Interior volume
l
cu.ft.
20
0.7
53
1.9
115
4.1
240
8.6
400
14.3
720
25.7
Steam space volume
l
cu.ft.
36
1.27
70
2.47
142
5.02
283
10.0
457
16.15
808
28.55
Racks
Quantity of racks (regular)
2
2
2
2
2
2
Quantity of racks (max.)
4
4
5
7
9
15
Load per rack
Kg
lbs
12
26
15
33
20
44
30
66
35
77
45
99
Permitted total load
Kg
lbs
25
55
40
88
50
110
70
155
90
199
120
265
Weight
Weight (empty)
Kg
lbs
27
60
43
95
61
135
93
205
135
298
191
422
Temperature data
Temperature range, 5 °C / 9 °F
above ambient up to
°C
°F
100
212
100
212
100
212
100
212
100
212
100
212
Temperature fluctuation
at 37 °C
± K
0.2
0.1
0.1
0.1
0.1
0.1
at 50 °C
± K
0.4
0.1
0.1
0.1
0.2
0.2
Temperature uniformity
(variation)
at 37 °C
± K
0.5
0.5
0.4
0.5
0.5
0.5
at 50 °C
± K
1.8
1.1
0.8
0.9
1.0
1.0
Heating up time
to 37 °C
minutes
59
92
70
98
120
110
to 50 °C
minutes
115
108
90
115
120
125
Recovery time after door
was opened for 30 sec
at 37 °C
minutes
20
15
10
7
10
15
at 50 °C
minutes
30
20
12
20
35
30
