BD/ED/FD (E2) Service Manual
State: 01/2002 Created: 06/2002 / Jochen Tussinger
BD/ED/FD (E2)
Service Manual
Version of chamber described in this service manual:
Standard equipped BD, ED, FD
with
R3 Controller

Table of Contents

Questions and Answers

  • D
    David MillerAug 15, 2025
    Why is my Binder climate chamber heating over the temperature setting?
    • A
      April CaldwellAug 15, 2025
      If your Binder climate chamber is overheating, there could be several reasons: 1. A defect in the solid state relay might be causing it. Consider replacing the solid state relay. 2. The controller itself may be faulty. Replacing the controller could solve the issue. 3. The PT100 sensor could be defective, leading to incorrect temperature readings. In this case, replace the PT100. 4. The controller might need calibration. Try calibrating the controller.
  • T
    tammylopezAug 18, 2025
    What to do if my Binder climate chamber doesn’t heat, but the indicator light is on?
    • D
      danielsnathanAug 18, 2025
      If your Binder climate chamber isn't heating, but the indicator light is on, the issue might stem from: * A defective solid state relay. Replacing it may resolve the problem. * Faulty heating elements. Replacing the heating element(s) could fix the issue.
  • C
    Corey ScottAug 21, 2025
    How to troubleshoot temperature reaching issues in a Binder climate chamber?
    • J
      James JohnsonAug 21, 2025
      If your Binder climate chamber isn't reaching the specified temperature within the expected time, consider these potential causes: * The chamber door may not be closing completely. Ensure the door is properly closed. * The door sealing might be damaged. Inspect and replace the door sealing if necessary. * The controller may require calibration. Calibrate the controller to ensure accurate temperature regulation.
  • P
    Patricia RangelAug 25, 2025
    What to do if my Binder climate chamber doesn’t heat and the indicator light is off?
    • S
      Susan StewartAug 26, 2025
      If your Binder climate chamber isn't heating, and the indicator light is off, it could be due to these reasons: 1. The safety device might have been triggered, switching off the chamber. Reset the safety device. 2. The timer might be off. Check and set the timer accordingly. 3. The controller could be defective. Consider replacing the controller.
  • A
    andrew83Aug 28, 2025
    Why my Binder climate chamber has no function?
    • J
      Julia WyattAug 28, 2025
      If your Binder climate chamber is not functioning, consider the following: * Incorrect connection: Check the connection. * Wrong address in the controller: Set the correct address in the controller. * Controller in Stand-By mode: Switch the controller out of Stand-By mode.
  • D
    Diana PetersSep 1, 2025
    What to check if my Binder climate chamber doesn’t do anything?
    • A
      andrea32Sep 1, 2025
      If your Binder climate chamber isn’t working, check the following: * Ensure the power supply cable is properly connected to the mains. * Verify the mains voltage (115V or 230V).
  • M
    Melissa RhodesSep 4, 2025
    Why is data transfer failing with APT-Com on my Binder climate chamber?
    • K
      kennethleeSep 4, 2025
      If you're experiencing issues with data transfer to and from APT-Com on your Binder climate chamber, despite correct installation, consider these potential causes: * The chamber address set at the controller might be incorrect. Ensure the correct chamber address is set. * The connection cable could be damaged. Replace the connection cable. * The switch at the converter might be incorrectly set to DCE. Ensure it is set to DTE. * The converter may not be receiving sufficient power. Check the power supply to the converter.
  • N
    nathanperezSep 7, 2025
    What to do if the glass door of my Binder climate chamber doesn’t close?
    • M
      Megan BoydSep 7, 2025
      If the glass door of your Binder climate chamber isn’t closing, it might be due to a defective plastic catcher. Replace the plastic catcher.
  • D
    debra09Sep 12, 2025
    What does it mean if only the green LED lights on my Binder climate chamber?
    • J
      Justin WolfSep 12, 2025
      The chamber is in Stand-by mode.

Summary

Chamber Functionality

R3 Controller I;O Description

Details the inputs and outputs of the R3 controller, including connections and signals.

Troubleshooting Guide

BD Chamber Troubleshooting

Lists common faults for BD chambers and their potential causes.

ED Chamber Troubleshooting

Lists common faults for ED chambers and their potential causes.

FD Chamber Troubleshooting

Lists common faults for FD chambers and their potential causes.

APT-COM Connectivity Issues

Addresses and resolves common problems with APT-COM data transfer.

Common Service Procedures

Replacing the R3 Controller

Provides step-by-step instructions for replacing the R3 controller unit.

Changing the FD (E2) Chamber Fan

Detailed instructions for removing and replacing the fan in FD (E2) chambers.

One Point Calibration Procedure

APT-COM Integration

R3 Controller APT-COM Settings

Single Chamber APT-COM Connection

Binder BD Specifications
