Binks TROPHY 2466 SERIES - Page 5

EN
77-3027-R1.0 5 / 16
ITEM
NO.
PART
NUMBER
DESCRIPTION
QTY.
1 54-6120
AIR CAP RETAINING RING
ASSEMBLY
1
5
SEE CHARTS
ON PAGE 7
AIR CAP 1
6 JGA-156-K10 SPRING-CLIP (KIT OF 10) 1
7
SEE CHARTS
BELOW
FLUID NOZZLE 1
8 54-6102-K3 BAFFLE/SEPARATOR (KIT OF 3) 1
9 54-6122 SIDE PORT VALVE ASSEMBLY 1
10 ------
+
6
RETAINING CLIP 1
11 ------
+
BODY BUSHING 1
12 ------
+
6
O-RING 1
13 ------
+
SIDE PORT STEM 1
14 ------
+
6
PIN 1
15 54-6131-K AIR VALVE SERVICE KIT 1
16 ------
•
FRONT SEAL – AIR VALVE 1
17 ------
•
FRONT AIR VALVE SEAL 1
18 54-6109 AIR VALVE SPINDLE 1
19 ------
•
AIR VALVE SPRING 1
20 ------
•
REAR SEAL – AIR VALVE 1
21 SN-66 HOUSING 1
22 47-6825 NEEDLE – STAINLESS STEEL (STD.) 1
23 54-6133-K3 SPRING/PAD ASSEMBLY (KIT OF 3) 1
ITEM
NO.
PART
NUMBER
DESCRIPTION
QTY.
24 54-6111 KNOB – NEEDLE ADJUSTING 1
25 54-6130-K NEEDLE PACKING KIT (STANDARD) 1
26 ------
n
NUT – PACKING 1
27 ------
n
SPRING FOR PACKING 1
28 ------
n
▼
NEEDLE PACKING (STANDARD) 1
29 54-4360 TRIGGER 1
30 54-6132-K TRIGGER SCREW NUT KIT 1
31 ------
V
TRIGGER SCREW 1
32 ------
V
TRIGGER NUT 1
33 54-3513 SPINDLE CAP 1
34 SN-11 PLUG 1
35 54-6112 FITTING – AIR INLET 1
36 ------ GUN BODY WITH FLUID INLET 1
37 SPN-7 TOOL – SEAL INSERTION 1
38 ------ GUNNER'S MATE (3 CC BAG) 1
CHART 1: BINKS “TROPHY” SERIES GRAVITY SPRAY GUN PARTS LIST
CHART 3:
TEST AIR CAP KITS –
OPTIONAL
CONVENTIONAL
54-6141-K 12-C KIT
L V M P
54-6147-K 23-L KIT
HVLP
54-6152-K 32-H KIT – HVLP
CHART 2:
STAINLESS STEEL (HARDENED)
FLUID NOZZLES – STD.
STAINLESS FLUID NOZZLE
ORIFICE SIZE
FUID NOZZLE
PART NUMBER
.039" 1.0 mm 45-11050-10
.047" 1.2 mm 45-11050-12
.055" 1.4 mm 45-11050-14
.063" 1.6 mm 45-11050-16
.071" 1.8 mm 45-11050-18
+
PARTS INCLUDED IN
54-6122
n
PARTS INCLUDED IN
54-6130-K
▼
ALSO AVAILABLE IN KIT OF 3
SN-2-K3
•
PARTS INCLUDED IN
54-6131-K
V
PARTS INCLUDED IN
54-6132-K
6
GTI-428-K5 SIDE PORT
REPAIR KIT
