Connecting the cord
S-con nec tor
Con nect the S-cord
2
as shown in Fig. (so cket S0). Plea se note that the lon ger ISDN plug must be in ser ted in the
ISDN so cket and the shor ter ISDN plug must be in ser ted in the ISDN so cket on the sys tem te le pho ne. Next pla ce the
S-cord ca ble in the ca ble gui de
4
and clamp it se cu re ly un der the ca ble clips
5
.
