BIO UV MP 100 - Technical Characteristics

MP EL
-
GB
COPYRIGHT BIO
-
UV
-
29/01/2009
MARQUE, MODELES ET BREVETS DEPOSES - PRODUITS EXCLUSIFS
PAGE
4
A. TECHNICAL CHARACTERISTICS
MP RANGE MP 100
EL
MP 125
EL
MP 140
EL
MP 240
EL
MP 340
EL
MP 440
EL
REACTOR
Material
Stainless steel 316L
Finish
Pickling and passivated
Maximum service pressure
10 bars
Weight (kg)
(1)
40 37 50 55 55 60
Ø and body length (mm)
273 x 1175 273 x 1152 355 x 1244 355 x 1020 355 x 720 355 x 824
Overall length (mm)
1175 1152 1244 1020 720 824
Volume (litres)
45 50 90 85 65 75
Connection type
Flange Flange Flange Flange Flange Flange
Standard Connection
(2)
DN 125 DN 150 DN 200 DN 250 DN 300 DN 300
ELECTRICAL UNIT
Type
Painted steel
Dimensions (mm)
600x400
x250
600x400
x250
600x400
x250
600x600x250 800x600x300 800x600x300
Weight (kg)
40 50 70 110 130 150
Power supply
Single phase
230V
50-60HZ
SINGLE
PHASE
230V
50-60HZ
SINGLE
PHASE
230V
50-60HZ
THREE-
PHASE
415V
TRI+NEUT
RAL
THREE-
PHASE
415V
TRI+NEUT
RAL
THREE-
PHASE
415V
TRI+NEUT
RAL
Power supply wiring
2G1.5mm² 2G2.5mm² 4G2.5mm² 4G6mm²
Earth cable
6 mm²
Differential protection
30mA
Thermo magnetic protection
10 A 10 A 16 A 25 A 25 A 40 A
Circuit breaker tripping curve
Curve C Curve D
Fuse
-
On / Off switch
Yes
Power on indicator light
Yes
UV lamp indicator light
Yes
Display
Monitor MIII
Protection index
IP 54
UV-C LAMP
Number of lamps
1 1 1 2 3 4
Electrical power
1,000 W 3,000 W 3,000 W 6,000 W 9,000 W 12,000 W
Unit UV-C power
150 W 375 W 475 W 475 W 475 W 475 W
Total UV-C power
150 W 375 W 600 W 1,200 W 1,800 W 2,400 W
Average lifetime
6 to 9,000 h 6 to 9,000 h 6 to 9,000 h 6 to 9,000 h 6 to 9,000 h 6 to 9,000 h
*operating continuously with one on/off per day.
Turning UV lamps on and off reduces their lifespan. A minimum time delay of 30 minutes must be
observed before turning a lamp back on again.
(1) Caution, with a cleaning system these values change.
(2) Except request specific to the order.
