4 PROTEQ DESCRIPTION
4.1 Main Module Features & Connections
4.1.1 Base Unit
Emergency
Process stop
Moulded
Handles
lectern –
Optional
Aeration units
stored behind.
Light ring
Aeration Unit
Braked Wheels
(2)
Top air inlet
filter
Air outlets (4)
Bottle
engagement
plunger
Wireless status
indicator
Bottle status
indication lights
Bottle
compartment
Safety
equipment
storage (Gloves
& goggles)
Air inlet must be kept
clear of obstructions
Power Switch
Power cable connection
Cycle stage volt free
signal
Remote start/stop
BACK PANEL
NOTE: The power cables supplied with the equipment must not be replaced with inadequately rated cables
