Bioquell ProteQ - 16 SPECIFICATION

BIOQUELL PROTEQ USER MANUAL -EN
TD092-O&M-001
REVISION 5 DRAFT
Page 48 of 58
16 SPECIFICATION
Materials of Construction:
(external surfaces)
• Polypropylene (PP)
• Acrylonitrile Butadiene Styrene (ABS)
• Aluminium Alloy (Epoxy coated)
•
Polyester/Polycarbonate Labels
Cycle Starting
Environmental Limiting
Conditions:
Temperature
Limits:
15°C to 30°C (59°F to 86°F)
1
Relative Humidity
Limits:
10% to 80% RH
2
Storage Environmental
Limiting Conditions:
Temperature
Limits:
0°C to 35°C (32°F to 95°F )
Relative Humidity
Limits:
80% RH (Max non-condensing)
Pollution Degree
Environment:
2
Power Requirements:
230V AC
Single phase, 50/60 Hz, (7.5A Base Unit, 1A
lectern)
120V AC
Single phase, 50/60Hz, (15A Base Unit, 2A
lectern)
100V AC
Single phase, 50/60Hz, (15A Base Unit, 2A
lectern)
Power Supply:
Installation category II
Power Consumption:
Base Unit / lectern
230V AC
1.8 kW max / 0.2kW max
120V AC
1.8 kW max / 0.2kW max
100V AC
1.8 kW max / 0.2kW max
Cable lengths (Mains
Power):
Base Unit
5m (16.4ft)
Lectern
3m (10 ft)
Operating Position:
Upright Only
Unit Dimensions (WxHxD)
Base Unit &
lectern
672 x 1430 x 710 mm (26.5 x 56.3 x 28.0in)
(Height=1421mm (56in) if no lectern)
Lectern
630 x 880x 349 mm (24.8 x 34.6 x 13.7in)
Unit Weight:
67 kg (148lbs), including Lectern, not including
bottles or Aeration units
Lectern Weight:
9 kg (20lbs)
Packaged Dimensions:
(WxHxD)
900 x 1560 x 820mm (35.4 x 61.4 x 32.2in)
Packaged Gross Weight:
115kg (254lbs)
Locking Brake:
(2x) Castor Lock
Data Printer
Thermal print record
Human interface
Colour touch screen
1
The ProteQ will allow a cycle to start up to a maximum of 35°C (95°F) starting temperature. However
when operating above 30°C please contact Bioquell to ensure the correct cycle set-up
2
If requiring to operate outside this range refer to Bioquell or its agents
