BIOQUELL PROTEQ USER MANUAL -EN
TD092-O&M-001
REVISION 5 DRAFT
Page 49 of 58
External Connections:
Base Unit
Lectern
• Mains Power Supply
• Cycle status signal digital (volt free) outputs
(requires voltage from external equipment)
• Start/stop (run) signal 24VDC input (requires
volt free connection at external equipment)
• Mains Power Supply
• RJ-45 connector on lectern for Ethernet
communications (Protocol: Modbus TCP/IP
and OPC UA)
•
Wireless range extender
Wireless Interface:
2.4 GHz ISM Band, 16 channels (IEEE802.15.4
Channels 13,15,19,20,25), Zigbee, Maximum
power 3dBm
Optional additional
Aeration Capability
2 off onboard stored, free standing wirelessly
controlled units. Independently powered 100-
240V (3.1A). Upto 6 can be operated
Maximum H
2
0
2
liquid
injection rate
230V/120V
4 to 16 g/min
Flexi Adaptor
4 to 12 g/min
100V
4 to 10 g/min
Enclosure decontamination
capacity
Nominally 400 m
3
(14,130ft
3
) for rooms
(subject to configuration, loading and
environmental conditions, lower limit 250m
3
(8,830ft
3
) at 30°C (86°F) and 10% RH)
Maximum H
2
0
2
liquid
volume
Capacity
4 litres (135 fl oz)
Injection Pump Accuracy
±1.5%
H
2
0
2
Liquid concentration
35% w/w. Bioquell approved supply only
Radio Frequency
Identification of H
2
O
2
bottles
ISO1443 Type A (13.56 MHz), Maximum power
<1 linear mW
Noise: Outside room over
a cycle L
Aeq
64.2 dB (A)
