BIOQUELL PROTEQ USER MANUAL -EN
TD092-O&M-001
REVISION 5 DRAFT
Page 42 of 58
Alarm
No.
Alarm Name
Alarm
Description
Action
User Action
21
Air heater fan 1
fault
Air heater fan 1 has
stopped working
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Aerate until room
reaches 1ppm and
contact service provider
22
Air heater fan 2
fault
Air heater fan 2 has
stopped working
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Aerate until room
reaches 1ppm and
contact service provider
23 Cycle abort by user
The cycle has been
aborted by means of
the stop button on
the HMI
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
If in emergency aeration will
stop cycle.
Aerate until room
reaches 1ppm and
contact service provider
24 Power failure
Power has been lost
during a cycle and
resumed
Will go to off mode when
power restored.
Start aeration cycle and
aerate until room
reaches 1ppm, then re-
run cycle
25 Emergency aeration
Unit has gone into
emergency aeration
due to another fault
Unit is in emergency
aeration
Aerate until room
reaches 1ppm
26
Aeration unit 1
main fan failure
(if present)
Main aeration fan has
stopped working
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Aerate until room
reaches 1ppm, and
contact service provider
27
Aeration unit 1
distribution fan 1
failure
(if present)
Aeration distribution
fan has stopped
working
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
Aerate until room
reaches 1ppm, then re-
run cycle with other
aeration units and
contact service provider
28
Aeration unit 1
distribution fan 2
failure
(if present)
Aeration distribution
fan has stopped
working
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
Aerate until room
reaches 1ppm, then re-
run cycle with other
aeration units and
contact service provider
29
Aeration unit 2
main fan failure
(if present)
Main aeration fan has
stopped working
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Aerate until room
reaches 1ppm, and
contact service provider
30
Aeration unit 2
distribution fan 1
failure
(if present)
Aeration distribution
fan has stopped
working
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
Aerate until room
reaches 1ppm, then re-
run cycle with other
aeration units and
contact service provider
31
Aeration unit 2
distribution fan 2
failure
(if present)
Aeration distribution
fan has stopped
working
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
Aerate until room
reaches 1ppm, then re-
run cycle with other
aeration units and
contact service provider
