BIOQUELL PROTEQ USER MANUAL -EN
TD092-O&M-001
REVISION 5 DRAFT
Page 44 of 58
Alarm
No.
Alarm Name
Alarm
Description
Action
User Action
43
Aeration unit 6
distribution fan 2
failure
(if present)
Aeration distribution
fan has stopped
working
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
Aerate until room
reaches 1ppm, then re-
run cycle with other
aeration units and
contact service provider
44
Aeration unit
communications
lost In cycle
(if present)
One of the aeration
units as defined in
the cycle setup, is no
longer
communicating
Will stop cycle prior to
gassing stage, otherwise will
go into emergency aeration.
Aerate until room
reaches 1ppm, then re-
pair the aeration unit, if
does not work replace
unit.
45
HMI communication
error
The communication
between the HMI and
the vaporizer module
has been lost
Unit will go into emergency
aeration
Aerate until room
reaches 1ppm, then re-
pair the vaporizer
module. If does not
work contact service
provider.
46
RH sensor fault -
RH
The RH sensor is
reading a low RH
value due to a fault
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Aerate until room
reaches 1ppm and
contact service provider
47
RH sensor fault -
temperature
The temperature
sensor is reading a
low temperature
value due to a fault
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Aerate until room
reaches 1ppm and
contact service provider
48 Insufficient Liquid
Parametric cycle
only.
Will stop cycle at the end of
conditioning stage.
More H202 required.
Restart the cycle.
49
Starting
temperature Low
The room
temperature is below
15°C
Will prevent a cycle from
starting
Increase the
temperature in the
room to above 15°C
50
Starting
temperature High
The room
temperature is above
35°C
Will prevent a cycle from
starting
Reduce the
temperature in the
room to below 35°C
52 Starting RH High
The RH sensor is
reading 100% RH or
higher
Will prevent a cycle from
starting
Faulty sensor - Contact
service provider
53 EMM Fan Fault
The fan on the
environmental
monitoring module is
not rotating
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Faulty EMM - Contact
service provider
54
Internal Aeration
Fan1 Fault
Fan has stopped
working
Will go into emergency
aeration.
Contact service
provider
55
Internal Aeration
Fan2 Fault
Fan has stopped
working
Will go into emergency
aeration.
Contact service
provider
56 Remote Stop
External input is not
present when
required, usually
from Building
Management System
or other controller.
Will prevent a cycle from
starting. If in cycle prior to
gassing will stop the cycle,
otherwise will go to
emergency aeration
Investigate the external
system.
Check Remote
Start/Stop leads and
connections to unit.
