18 | Chapter 2: Hardware installaon
M2M_CPU: M.2 (M Key) Socket
• The M.2 slot supports M.2 Type 2280 SSD module. When installing M.2 SSD module,
please place the M.2 Anchor to correct posion.
• Supports M.2 PCI Express module up to Gen4x4 (64Gb/s) - NVMe SSD.
M2M_SB: M.2 (M Key) Socket
• The M.2 slot supports M.2 Type 2242/ 2260/ 2280 SSD module. When installing M.2 SSD
module, please place the M.2 Anchor to correct posion.
• Supports M.2 PCI Express module up to Gen4x4 (64Gb/s) - NVMe SSD
M2E_WIFI: M.2 (E Key) Socket (M.2 (E key) Wi-Fi card is not provided)
• Support M.2 socket 2230 type module.
• Supports WiFi/ Bluetooth module and Intel® CNVi (Integrated WiFi/ BT).
To Next Page
