1�3 Specifications
Specicaons
CPU Support
Support for 12th / 13th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/
Intel® Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® B760
Memory
Supports Dual Channel DDR5 - 6000+(OC) / 6000(OC) /5800(OC) / 5600(OC)/ 5400(OC)/
5200(OC)/ 5000(OC)/ 4800
4x DDR5 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Each DIMM supports non-ECC 8/16/32GB DDR5 module
Support Intel® Extreme Memory Prole (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 2x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 (M Key) Socket (M2M_CPU):
Supports M.2 Type 2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe SSD
1x M.2 (M Key) Socket (M2M_SB):
Supports M.2 Type 2242/2260/2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe SSD
RAID Supports RAID 0, 1, 5,10 for SATA storage devices
LAN
Realtek RTL8125B
10/ 100/ 1000/ 2500 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC897
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
1x USB 3.2 (Gen2) Type-C port (1 via internal header)
5x USB 3.2 (Gen1) port (3 on rear I/Os and 2 via internal header)
6x USB 2.0 port (2 on rear I/Os and 4 via internal header)
Expansion Slots
1x PCIe 4.0 x16 Slot (x16 mode)
1x PCIe 3.0 x16 Slot (x4 mode)
1x PCIe 3.0 x1 Slot
Rear I/Os
B760MZ-E PRO
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x DP
1x VGA
1x DVI Port
3x USB 3.2 (Gen1) Port
2x USB 2.0 port
1x LAN port
3x Audio Jack
B760MX-E PRO
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA Port
1x DVI Port
3x USB 3.2 (Gen1) Port
2x USB 2.0 port
1x LAN port
3x Audio Jack
B760MH-E PRO
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA Port
3x USB 3.2 (Gen1) Port
2x USB 2.0 port
1x LAN port
3x Audio Jack
B760MP-E PRO
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x DP
1x HDMI
1x DVI Port
3x USB 3.2 (Gen1) Port
2x USB 2.0 port
1x LAN port
3x Audio Jack

Biostar B760MZ-E PRO Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9
Maximum number of SMP processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	5000, 5200, 5400, 5600, 5800, 6000 MHz
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	-
USB 2.0 connectors	2
EPS power connector (8-pin)	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Wi-Fi	No
LAN controller	Realtek RTL8125B
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel B760
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
Cables included	SATA

Weight and Dimensions

Width	244 mm
