Biostar G41D3C User Manual

G41D3C BIOS Manual
25
South Bridge Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
South Bridge Chipset Configuration
USB 2.0 Controller [Enabled]
Audio Controller [Azalia]
Onboard Lan Control [Enabled]
Onboard Lan Boot ROM [Disabled]
SMBUS Controller [Enabled]
SLP_S4# Min. Assertion Width [1 to 2 seconds]
USB Functions [8 USB Ports]
MAC ID Information
Options
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
USB Functions
The item determines the number of functional USB port.
Options: 8 USB Ports (Default) / 6 USB Ports / 4 USB Ports / 2 USB Ports /
Dis abled
USB 2.0 Controller
This entry is to enabled/ disabled EHCI controller only. This Bios itself may/may not
have high speed USB support. If the Bios has high speed USB support built in,the
support will be automately turn on when high speed device were attached.
Options: Enabled (Default) / Disabled
Audio Controller
This item allows you to select the Audio support.
Options: Azalia (Default) / All Disabled
Onboard Lan Control
This item allows you to enable o r dis able the Onbo ard LAN.
Options: Enabled (Default) / Disabled

Biostar G41D3C Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
Socket	LGA 775
Memory Type	DDR3
Memory Slots	2
Maximum Memory	8 GB
Integrated Graphics	Intel GMA X4500
Storage Interface	4 x SATA 3Gb/s
Video Outputs	1 x VGA
Audio	Realtek ALC662 6-Channel HD Audio
IDE Ports	1 x IDE
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111E
Expansion Slots	1 x PCIe x16, 1 x PCIe x1, 2 x PCI
