Biostar G41D3C User Manual

G41D3C BIOS Manual
28
PCIE Clock By
This item allows you to select the PCIE clock control
Options: Auto (Default) / Manual
PCIE Frequency Setting
This item allows you to select the PCIE clock control
Options: 100 (Default) / Min=100; Max=150
DRAM Frequency
This item allows you to control the Memory Clock.
Options: Auto (Default) /DDR3 800Mhz / DDR3 1066Mhz
Configure DRAM Timing by SPD
Options: Enabled (Default) / Disabled
DRAM tCL
Opt io ns: 7 ( Def a ult) / 3 ~ 1 0
DRAM tRAS
Options: 20 (Default) / 9 ~ 24
DRAM tRP
Opt io ns: 7 ( Def a ult) / 3 ~ 1 0
DRAM tRCD
Opt io ns: 7 ( Def a ult) / 3 ~ 1 0
DRAM tWR
Opt io ns: 8 ( Def a ult) / 3 ~ 1 5
DRAM tRFC
Options: 60 (Default) / 15 ~ 150

Biostar G41D3C Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
Socket	LGA 775
Memory Type	DDR3
Memory Slots	2
Maximum Memory	8 GB
Integrated Graphics	Intel GMA X4500
Storage Interface	4 x SATA 3Gb/s
Video Outputs	1 x VGA
Audio	Realtek ALC662 6-Channel HD Audio
IDE Ports	1 x IDE
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111E
Expansion Slots	1 x PCIe x16, 1 x PCIe x1, 2 x PCI
