12 | 第二章:硬體安裝
第二章:硬體安裝
2�1 中央處理器(CPU)
步驟1: 找到主板上的CPU插槽。
»
安裝前請取掉針腳保護蓋並妥善保管備使用移開CPU後請蓋上保護蓋以確保針腳不會被
壞。
»
主板可能配有兩種不同的針腳保護蓋請參照以下示取掉保護蓋
步驟 2: 將 ILM 拉桿向上抬起並將 CPU 保護蓋掀起。
步驟 3: 將處理器對準插槽上相對應位置。
