Biostar H610MX-E User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support for 12th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/
Intel® Celeron® processors in the LGA1700 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® H610
Memory
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200
2x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
Support Intel® Extreme Memory Prole (XMP) memory modules
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 1x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s)
1x M.2 (M Key) Socket (M2_PCIEG3_32G_ SATA):
Supports M.2 Type 2240 /2260 /2280 SSD module
Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA SSD
LAN
Intel® I219V
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC897
7.1 Channels, High Denion Audio
USB
4x USB 3.2 (Gen1) port (2 on rear I/Os and 2 via internal headers)
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 3.0 x1 Slot
1x PCIe 4.0 x16 Slot
Rear I/Os
H610MX-E
1x WIFI Antenna Port
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA+DVI Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MH-E
1x WIFI Antenna Port
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MX
1x PS/2 Keyboard/
Mouse Port
1x HDMI
1x VGA+DVI Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
H610MH / H610MHP / H610MHC
1x PS/2 Keyboard/ Mouse Port
1x HDMI
1x VGA Port
2x USB 3.2 (Gen1) port
4x USB 2.0 port
1x LAN port
3x Audio Jack
Internal I/Os
H610MX-E / H610MH-E
4x SATA III Connector (6Gb/s)
1x M.2 (E Key) Socket : Supports 2230 type Wi-Fi
& Bluetooth module and Intel® CNVi
2x USB 2.0 Header (each header supports 2 USB
2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports
2 USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
* M.2 (E key) Wi-Fi card is not provided
H610MX / H610MH / H610MHP / H610MHC
4x SATA III Connector (6Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2
(Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
1x TPM Header
Form Factor uATX Form Factor, 208 mm x 236 mm
OS Support
Windows 10(64bit) / Windows 11(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar H610MX-E Specifications

General

Brand	Biostar
Model	H610MX-E
Category	Motherboard
Language	English
