Biostar H61MHV3 User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support Intel® Core™ i7/ i5/ i3 processors and Intel® Penum® processors/ Intel® Celeron® processors
in the LGA1155 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® H61
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* DDR3 1600 memory module (depending on CPU)
* Please refer to www.biostar.com.tw for Memory support list.
Storage 4x SATA II (3Gb/s)
LAN
Realtek RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC897
7.1 Channels, High Denion Audio
USB 8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 2.0 x1
1x PCIe 3.0 x16 Slot (x16 mode, depending on CPU)
Rear I/Os
1x PS/2 Keyboard / Mouse
1x VGA Port
1x HDMI Port
4x USB 2.0 Port
1x LAN port
3x Audio Jack
Internal I/Os
4x SATA II (3Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Internal Stereo Speaker Header
1x Clear CMOS Header
1x COM Port Header
Form Factor uATX Form Factor, 191 mm x 170 mm
OS Support
Windows 7/ 8/ 8.1/ 10
Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar H61MHV3 Specifications

General

Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	- GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 16GB, 512MB
Number of storage drives supported	4
Supported storage drive interfaces	SATA II
Parallel processing technology support	-
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
LAN controller	Realtek RTL8111H
Ethernet interface type	10 Gigabit Ethernet, 100 Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
PCI Express slots version	2.0, 3.0
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
Height	191 mm
