4 | 第一章: 主板介绍
1�3 主板特性
規格
CPU支援
支援LGA1155插槽,Intel® Core™ i7 / i5 / i3處理器和Intel® Pentium®處理器/
Intel® Celeron®處理器
* 請瀏覽映泰網站 www.biostar.com.tw 獲得CPU的支援列表
晶片組 Intel® H61
記憶體
支援雙通道DDR3 1066/ 1333/ 1600
2x DDR3 DIMM插槽,支援最高容量為16GB
每根DIMM支援non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3記憶體模組
* DDR3 1600記憶體模組(取決於CPU)
* 請瀏覽映泰網站 www.biostar.com.tw 獲得記憶體的支援列表
儲存 4x SATA II接頭 (3Gb/s)
網路
Realtek RTL8111H
10/ 100/ 1000 Mb/s 半/全雙功能,自動協商模式
音效
ALC897
7.1聲道,支援高解析音效輸出
USB 6x USB 2.0連接埠(後側面板4個連接埠,內建接頭支援4個連接埠)
擴充插槽
1x PCIe 2.0 x1插槽
1x PCIe 3.0 x16插槽 (x16模式, 頻寬取決於CPU)
後側面板接頭
1x PS/2鍵盤/滑鼠連接埠
1x VGA連接埠
1x HDMI連接埠
4x USB 2.0連接埠
1x LAN連接埠
3x 音效接孔
內建接頭連接埠
4x SATA III接頭 (6Gb/s)
1x USB2.0連接埠(每個接頭支援2個USB2.0連接埠)
1x 電源插槽(4-pin)
1x 電源插槽(24-pin)
1x CPU風扇接頭
1x 系统風扇接頭
1x 前置面板接頭
1x 前置音效接頭
1x 內部立體聲揚聲器接頭
1x 清除CMOS組態資料接頭
1x 序列埠接頭
主板尺寸 uATX型式規格,191 mm x 170 mm
操作系統支援
Windows 7/ 8/ 8.1/ 10
* 如有增加或減少任何OS支援,Biostar保留不預先通知的權利。
