Biostar H61MHV3 User Manual

목차 | 3
H61MHV3
목차
챕터 1: 들어가는 글 ������������������������������������������������������������������������������������������������4
1.1 시작하기에 앞서 ................................................................................................................................4
1.2 패키지 체크리스트 ...........................................................................................................................4
1.3 사양 ........................................................................................................................................................5
1.4 후면 패널 커넥터 ..............................................................................................................................6
1.5 메인보드레이아웃 .............................................................................................................................7
챕터 2: 하드웨어 설치 ��������������������������������������������������������������������������������������������8
2.1 CPU 설치 ..............................................................................................................................................8
2.2 CPU 쿨러 설치 ................................................................................................................................10
2.3 쿨링팬연결 .......................................................................................................................................11
2.4 시스템 메모리 설치.......................................................................................................................11
2.5 확장 슬롯 ..........................................................................................................................................13
2.6 점퍼 & 스위치 설정 ......................................................................................................................14
2.7 헤더 & 커넥터 ...............................................................................................................................15
챕터 3: UEFI 바이오스 & 소프트웨어 ���������������������������������������������������������������� 18
3.1 UEFI 바이오스 설정 .......................................................................................................................18
3.2 바이오스 업데이트 ........................................................................................................................18
3.3 소프트웨어 .......................................................................................................................................22
챕터 4: 유용한 도움말 ����������������������������������������������������������������������������������������� 23
4.1 드라이버 설치 .................................................................................................................................23
4.2 AMI 바이오스 비프음 코드 ........................................................................................................24
4.3 AMI 바이오스 포스트 코드 ........................................................................................................24
4.4 문제해결 ............................................................................................................................................26

Biostar H61MHV3 Specifications

General

Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	- GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 16GB, 512MB
Number of storage drives supported	4
Supported storage drive interfaces	SATA II
Parallel processing technology support	-
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
LAN controller	Realtek RTL8111H
Ethernet interface type	10 Gigabit Ethernet, 100 Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
PCI Express slots version	2.0, 3.0
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
Height	191 mm
