H77MU3 UEFI BIOS Manual
37
DDR DRAM Multiplier
This item allows you to set DDR3 DRAM Multiplier.
Options: 14(Default) / 16 / 18 / 20 / 22 / 26 / 28
CAS# Latency (tCL)
This item allows you to select CAS Latency of DDR3.
Opt io ns : 9 ( Defau lt) / 3 ~ 15
Row Precharge Time (tRP)
This item allows you to select Row Precharge Time of DDR3.
Opt io ns : 9 ( Defau lt) / 3 ~ 15
RAS# to CAS# Delay (tRCD)
This item allows you to select Row Address to Column Address Delay of DDR3.
Opt io ns : 9 ( Defau lt) / 3 ~ 15
RAS# Active Time (tRAS)
This item allows you to select Row Active Time of DDR3.
Options: 24 (Default) / 9 ~ 63
Write Recovery Time (tWR)
This item allows you to select Internal Write to Read Command Delay of DDR3.
Options: 10 (Default) / 3 ~ 31
Row Refresh Cycle Time (tRFC)
This item allows you to select Minimum Refresh Recovery Time of DDR3.
Options: 107 (Default) / 15 ~ 255
Write to Read Delay (tWTR)
This item allows you to select Internal Write to Read Command Delay of DDR3.
Opt io ns : 5 ( Defau lt) / 3 ~ 31
