Biostar M7VKQ User Manual

Chapter 1 Motherboard Description
1-32
1.7.5.1 CD-ROM Audio-In Connector: JCDIN1
Pin No. Assignment
1
Left Channel Input
2
Ground
3
Ground
4
Right Channel Input
1.7.5.2 Front Panel Audio Connector: JAUDIO1
Pin No. Assignment Pin No. Assignment
1
Mic In
2
Ground
3
Mic Power
4
Audio Power
5
AUD FPOUT R
6
AUD RET R
7
Reserved
8
Key
9
AUD FPOUT L
10
AUD RET L
1.7.5.3 Telephony Audio Connector: JTAD1
Pin No. Assignment
1
PHONE_IN
2
Ground
3
Ground
4
MONO_OUT
