Chapter 1 Motherboard Description
1-17
1.6 Connectors, Headers & Jumpers
The connectors, headers and jumpers introduced below provide you lots of
capabilities such as power supply, front panel signal revelation, IDE hard disk
connection, floppy disk connection, Wake On LAN function and USB connection.
Noticeably, a jumper has two or more pins covered by a plastic jumper cap,
allowing the user to select a different system options.
JUSB2
1
2
9
10
JWOL1
1
JCMOS1
1
JATXPWR1
JPANEL1
IDE 1-2
FDD1
JAMRS1
JKBV1
1
SOCKET A
DIMM1
DIMM2
VT8361
VT82C686
BIOS
1
To Next Page
