BIRD THRULINE 4027F series Instruction Book

Bird 4421 RF Power Meter
50
Specifications, Cal Cart
To determine the model numbers of th e Cal Cart components, refer to the
model number breakdown on page viii. Fo r load specifications, refer to the
load manual included.
Note: Certain sensors or connectors ma y be incompatible with some
models. Refer to the model number breakd own on page viii for a list of avail-
able components, or contact Customer Service.
Max. Power
Under normal operating conditions, th mum power is the
MINIMUM of the max. power of the sens or and the max. power of the load.
The following modifiers apply:
Frequency Derating", page 57.
Due to the wide variety of availa ble connectors, frequency range and
maximum power may be reduced. Insertion loss is specified with female N
connectors. Choose connectors appropri ate for the frequency and power of
operation.
Derate RF power by 2.5% for every 305m (1,000 ft.) above 1,520m (5,000
ft.).
Bird Cal Cart
Frequency Range Sensor dependent, 30 MHz max.
Power Range Dependent on sensor, sensor connectors, and load
Connectors
Customer specified (See Chapter 6 "Available
Connectors", page 59)
Dimensions
Short Cart
Long Cart
Weight, Nominal
Short Cart
Long Cart
175 lbs. (80 kg)
290 lbs. (114 kg)
Temperature Range
Operating
Storage
0 to +35 °C (32 to +95 °F)
Altitude 1520 m (5000 ft.)
Humidity 85% noncondensing max
Calibration Cycle, Nominal 1 year
CE
CE Compliant. Refer to Declaration of Conformity for
specific standards.
