BIRO F1000N - Page 17

14
DescriptionItem No.
F9306300
Bearing 51108 40 x 60 x 13
F9308400
Bushing, 40 x 52 x 20, HK4020
F9308401
Ring IR 35 x 40 x 20.5
F9312101
Key 8 x 7 x 30
F9313702
Paddle Complete, SS
F93M0001
Hopper base
Description
Item No.
F93M0007
Hinge
F93M0008
Safety switch enclosure
F93M0082
O-Ring 3218
F93Z9D25
Ring external M25
FZ9AMR
Drum safety contact
F93M9347
Retaining ring
GPA41
Bearing, 6005 25 x 47 x 12
GVT126
Flat washer, M6, SS
GVT327
Socket head screw, M6-1.0 x 16, SS
GVT399
1-Way screw, M5-0.8 x 10, SS
F93M0131A
Drum cover assembly
F93M0110
Grease tting, M6
Fig No.
1
2
3
4
5
6
7
8
9
10
Fig No.
15
16
17
18
19
20
21
22
23
24
F93M0009
Left xed cover
F93M0018
Paddle shaft
F93M0021
Paddle drive gear
11
12
13
F93M0079
Seal, 38-56-10
GVT423
Flat head screw, M5-0.8 x 10, SS
14
25
GVT197
Hex head screw, M5-0.8 x 25, SS
F9315400
Snap ring D.33
HOPPER BASE AND PADDLE DRIVE
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
18
20
21
23
24
25
21
6
17
19
22
22
F93136V04T
Paddle Complete, SS Inline blades
