BIRO F1000N - Drum Drive

15
DescriptionItem No.
F9306300
Bearing 51108 40 x 60 x 13
F9306800
Seal AS 30 x 42 x 7 NBR
F9310701
Cam H32
F9312000
Pin 10 x 42
F9312101
Key 8 x 7 x 30
F93M0016
Drum shaft housing
Description
Item No.
F93M0019
Drum shaft
F93M0020
Drum shaft bearing housing
GVT020
Retaining ring, E28
GVT126
Flat washer, M6, SS
GG312
Key 5 x 5 x 14
GVT210
Hex head screw M6-1.0 x 25 SS
GVT312
Socket head screw, M5-0.8 x 12 SS
GVT033
Retaining ring, I55
GVT021
Retaining ring, E30
Fig No.
1
2
3
4
5
6
7
8
9
10
Fig No.
15
16
17
18
19
20
21
22
23
24
F93M0022
Drum drive gear
F93M0056
Shock absorber
F93M0083
O-ring 3300
11
12
13
F93M0111
Grease tting, M10-1.5 at 90°
GVT370
Socket head screw, M10-1.5 x 30 SS
14
25
GVT128
Flat washer M10, SS
FK30304
Bearing 6006 (30-55-13-2RS1)
GVT442
Set screw, M6-1.0 x 6 SS
GVT476
Cap for screw, M6
26
GZ7CUS
Inner ring, 25-30-26.5
GZ6CUS
Bushing, 30-37-12
1
2
2
3
4
5
5
6
7
8
9
10
11
12
13
21
15
16
17
18
19
20
14
22
23
24
25
26
DRUM DRIVE
