BIRO F1000N - Page 19

16
DescriptionItem No.
F9319600
Bearing,type 626-2RS, 19 x 6
F9321500
Plastic knob
F93M0031
Pinion
F93M0041
Cam, wire cleaner
F93M0042
Hub, cam
F93M0044
Oscillating support
F93M0045
Locking ring
F93M0054
Torsion spring
F93M0091P
Moving lever
F93M0074
Chain
Fig No.
1
2
3
4
5
6
7
8
9
10
15
F93M0055
Scraper support
F93M0057
Bushing, 25-28-35-11.5
11
12
13
F9308301
Master link, Chain, Not Shown
14
F93M0059
Recall pin
DescriptionItem No.
F93M0093
Moving shaft
GG270
Spacer
GG302
Wire cleaner locker assembly
GG309
Stud, Wire cleaner locker
GVT034
Retaining ring, internal M36
GVT086
Hex nut, M6-1.0, SS
GVT089
Hex nut, M12-1.75, SS
GZ6BCN
Bushing, 12-14-9
GVT448
Set screw cone pt, M8-1.25 x 10, SS
Fig No.
16
17
18
19
20
21
22
23
24
25
GVT208
Hex head screw, M6-1.0 x 16, SS
GVT314
Socket head screw, M5-0.8 x 16, SS
GVT316
Socket head screw, M5-0.8 x 25, SS
26
27
28
GVT329
Socket head screw, M6-1.0 x 25, SS
29
GVT446
Set screw cone pt, M5-0.8 x 5, SS
CLEANER CONTROL
F93M0090
Shaft support
1
2
3
4
5
6
7
8
9
10
10
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
GVT129
Flat washer, 12.3 dia, Not Shown
30
