BIRO F1000N - Motor and Gear Box

18
MOTOR AND GEAR BOX
DescriptionItem No.
F93M0011
Gear box
F93M0013
Pulley
F93M0014A
Motor support
F93M0014B
Plate for tightener
F93M0014C
Disc
F93M0015
Drive belt
F93M0028
Tightener pinion
F93M0029
Tightener pin
Fig No.
1
2
3
4
5
6
7
8
9
10
F93M9396
Motor, ½ HP, 230V-50/60Hz
GVT087
Hex nut, M8-1.25, SS
11
12
GVT126
Flat washer, M6, SS
GVT127
Flat washer, M8, SS
DescriptionItem No.
GVT135
Flat washer, 18 od. x 6 id
GVT136
Flat washer, 24 od. x 8 id
GVT208
Hex head screw, M6-1.0 x 16, SS
GVT209
Hex head screw, M6-1.0 x 20, SS
GVT230
Hex head screw, M8-1.25 x 16, SS
GVT234
Hex head screw, M8-1.25 x 35, SS
GVT347
Socket head screw, M8-1.25 x 12, SS
Fig No.
13
14
15
16
17
18
19
1
2
3
4
5
6
7
7
8
9
10
12
13
13
14
15
15
17
18
11 & 16
19
20
20
GVT458
Set screw at pt, M8-1.25 x 35, SS
