KB-206-1 13
7 Electrical connection
Semi-hermetic compressor, condenser fan and elec-
trical accessories correspond to the EU Low Voltage
Directive 2014/35/EU.
The ECOLITE condensing unit is provided exclusively
for the connection to TN-C-S or TN-S three-phase
power supply systems with a nominal voltage 230/400
V Δ/Y at a nominal frequency of 50 Hz. The connection
of a neutral conductor is mandatory. A nominal supply
voltage with qualitative characteristics according to DIN
EN 50160 is required. The ECOLITE condensing unit is
provided for a stationary installation.
Type Recommen-
ded fuse
Setting mo-
tor protec-
tion switch
LHL3E/2EES-2(Y) 18 A 8.0 A
LHL3E/2DES-2(Y) 10 A 9.5 A
LHL3E/2CES-3(Y) 13 A 11.0 A
LHL5E/4FES-3(Y) 13 A 11.5 A
LHL5E/4EES-4(Y) 16 A 14.5 A
LHL5E/4DES-5(Y) 16 A 16.0 A
LHL5E/4CES-6(Y) 20 A 20.0 A
Depending on the local conditions and applicable regu-
lations, the installation of a supply circuit disconnecting
device must be provided on site. The service switch
provided in the ECOLITE condensing unit does nor-
mally not fulfil the requirements regarding an electrical
disconnection of the device.
7.1 Schematic wiring diagram for ECOLITE
condensing units
Abbr. Component
B1 Controller
B3 High pressure transmitter (liquid line)
B4 Low pressure transmitter (suction gas
line)
C1 Operating capacitor fan 1
C2 Operating capacitor fan 2
F2 Fuse rating 230V
F3 Control circuit fuse
F5 High pressure switch
F6 Low pressure switch
K1 Main contactor
M1 Compressor
M1E Oil heater
M1Y1 CRII SV1
M1Y2 CRII SV2
M2 Fan 1
M3 Fan 2
OLC-K1 Oil monitoring
Q1 Service switch
R3 Discharge gas temperature sensor
R4 Ambient temperature sensor
R5 Cold store temperature sensor
R8 Suction gas temperature sensor
SE-B1 Protection device
T1 Control transformer
V1 Fan control module
Tab.5: Legend schematic wiring diagram ECOLITE
