KB-206-1 23
If room temperature control is set, the solenoid valve of
the liquid line is controlled according to the temperat-
ure. The capacity of the ECOLITE condensing unit con-
tinues to be controlled according to the suction pres-
sure. The suction pressure set point must therefore be
set to a sufficiently low value.
The external cold store temperature sensor is connec-
ted to the terminal strip X10 terminals 7 and 8. In deliv-
ery condition of the condensing unit, the suction gas
temperature sensor is connected to these terminals.
This sensor must be disconnected when the cold store
temperature sensor is connected and is therefore not
operational when the cold store temperature control is
active. BITZER cold store temperature sensors (NTC,
10kΩ@25°C) should be used. Other sensors are not
supported.
Compressor and CR II capacity regulator control –
menu CPr:
Menu item Function
F2+F4⇒PAR⇒CPr⇒SP1
Modbus: 16388
Set point of suction pressure regulator
-45.0 – 22.5°C
Setting ex factory: -10.0 °C
F2+F4⇒PAR⇒CPr⇒bHO
Modbus: 16389
Width of upper neutral band with 2 suction pressure regulators
0.0 – 20.0 K
Setting ex factory: 5.0 K
F2+F4⇒PAR⇒CPr⇒bH
Modbus: 16390
Width of upper neutral band with 1 suction pressure regulator
0.0 – 20.0 K
Setting ex factory: 2.0 K
F2+F4⇒PAR⇒CPr⇒bL
Modbus: 16391
Width of lower neutral band with 1 suction pressure regulator
0.0 – 20.0 K
Setting ex factory: 2.0 K
F2+F4⇒PAR⇒CPr⇒bLO
Modbus: 16392
Width of lower neutral band with 2 suction pressure regulators
0.0 – 20.0 K
Setting ex factory: 5.0 K
F2+F4⇒PAR⇒CPr⇒OS1
Modbus: 16393
Set point adjustment of suction pressure set point via digital input
-50.0 – 50.0 K
Setting ex factory: 5.0 K
F2+F4⇒PAR⇒CPr⇒CrE
Modbus: 16394
Duration CR II valve(s) closed until compressor is shut off
0 – 120 s
Setting ex factory: 60s
F2+F4⇒PAR⇒CPr⇒tAC
Modbus: 16395
Delay in change of upper neutral band
0 – 120 s
Setting ex factory: 10s
F2+F4⇒PAR⇒CPr⇒tdC
Modbus: 16397
Delay in change of lower neutral band
0 – 120 s
Setting ex factory: 10s
F2+F4⇒PAR⇒CPr⇒OFC
Modbus: 16399
Minimum duration compressor stop ⇒ compressor start
0 – 1200 s
Setting ex factory: 60s
F2+F4⇒PAR⇒CPr⇒OnC Minimum duration compressor start ⇒ compressor start
