KB-206-1 25
Menu item Function
Modbus: 16413 0.0–7.5 V
Setting ex factory: 4.0 V
F2+F4⇒PAR⇒FAn⇒Cit
Modbus: 16414
Duration of start phase of condenser fan(s)
0 – 120s
Setting ex factory: 5s
F2+F4⇒PAR⇒FAn⇒EdC
Modbus: 16417
Enable ambient temperature compensation
0 = operation without compensation
1 = operation with compensation
Setting ex factory: 1 = with compensation
F2+F4⇒PAR⇒FAn⇒dtC
Modbus: 16418
Temperature difference between temp. at condensing press. set point and am-
bient temp.
0.0 – 50.0 K
Setting ex factory: 10.0 K
F2+F4⇒PAR⇒FAn⇒CSH
Modbus: 16419
Maximum condensing pressure set point during compensation
10.0 – 80.0°C
Setting ex factory: 55.0°C
F2+F4⇒PAR⇒FAn⇒CSL
Modbus: 16420
Minimum condensing pressure set point during compensation
10.0 – 80.0°C
Setting ex factory: 15.0°C
F2+F4⇒PAR⇒FAn⇒LnE
Modbus: 16498
Enable LowSound operation of condenser fans
0 = LowSound operation deactivated (Eco operation active)
1 = LowSound operation activated
Setting ex factory: 0 = LowSound operation deactivated
F2+F4⇒PAR⇒FAn⇒ASL
Modbus: 16517
Discharge gas temperature for minimum speed of additional fan
50.0 – 150.0°C
Setting ex factory: 105°C
F2+F4⇒PAR⇒FAn⇒ASH
Modbus: 16518
Discharge gas temperature for maximum speed of additional fan
50.0 – 150.0°C
Setting ex factory: 110°C
F2+F4⇒PAR⇒FAn⇒ALP
Modbus: 16519
Signal level for minimum speed of additional fan
0.0–10.0 V
Setting ex factory: 1.0 V
F2+F4⇒PAR⇒FAn⇒AMP
Modbus: 16520
Signal level for maximum speed of additional fan
1.0–10.0 V
Setting ex factory: 10.0 V
The speed of the condenser fan(s) is controlled by
means of a phase angle control. The speed from 0 –
100% is transmitted in the form of a 0 – 10V signal to
the phase angle control module by the ECOLITE con-
troller.
The additional fan is an EC fan with a speed set point
setting 0 – 10V. The additional fan is controlled de-
pending on the discharge gas temperature. The opera-
tion is independent of the other operating conditions of
the condensing unit.
