BIXOLON Srp-275III User Manual

Rev. 1.01
- 16 -
SRP-275III
3-1-1 DIP Switch setting for Citizen(iDP 3550) mode
• DIP Switch 1
Switch
Function
ON
OFF
Default
1-1
Emulation Selection (*1)
Refer to the following table
OFF
1-2
1-3
Auto cutter
Enable
Disable
OFF
1-4
CBM command
CBM2 mode
(iDP3530 system)
CBM1 mode
(iDP3540 system)
OFF
1-5
International characters (*2)
Refer to the following table
ON
1-6
1-7
1-8
CR mode
CR
CR+LF
OFF
• DIP Switch 2 (RS232C serial interface model)
Switch
Function
ON
OFF
Default
2-1
Word length
8 bits
7 bits
ON
2-2
Parity check
Disable
Enable
ON
2-3
Parity selection
ODD
EVEN
ON
2-4
Hand shaking
DTR/DSR
XON/XOFF
ON
2-5
Baud rate selection (*3)
Refer to the following table
OFF
2-6
2-7
Near end switch
Enable
Disable
OFF
2-8
Mechanism type
Graphic
Character
OFF
NOTES
(*1) Emulation Selection (DSW 1-1 and 1-2)
Emulation
1-1
1-2
BXL/POS
OFF
OFF
BXL/POS-KP
ON
ON
STAR
OFF
ON
CITIZEN
ON
OFF
- BXL/POS-KP(Kitchen Printer mode) : A alarm is generated by printer after auto cutting
and in paper end error.
(*2) International Character Selection
No.
Country
DSW 1-5
DSW 1-6
DSW 1-7
Code page
U.S.A.
ON
ON
ON
Page 0 (PC437 : U.S.A.)
France
OFF
ON
ON
Page 2 (PC850 : Multilingual)
Germany
ON
OFF
ON
U.K.
OFF
OFF
ON
Denmark
ON
ON
OFF
Page 5 (PC865 : Nordic)
Sweden
OFF
ON
OFF
Italy
ON
OFF
OFF
Page 2 (PC850 : Multilingual)
Windows Code
OFF
OFF
OFF
Windows Code
(*3) Baud rate selection (Transmission speed)
Transmission
2-5
2-6
2400 baud
ON
ON
4800 baud
OFF
ON
9600 baud
OFF
OFF
19200 baud
ON
OFF

BIXOLON Srp-275III Specifications

General

Ethernet LAN	No
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Gray
Type	POS printer
Print speed	5.1 lps
Print technology	Dot matrix
Maximum resolution	80 x 144 DPI
Flash memory	16 MB
Internal memory	64 MB
Built-in sensors details	Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
Media thickness	0.06 - 0.085 mm
Maximum roll diameter	83 mm
Supported paper width	76.5 mm
Maximum printing width	63.5 mm
Power source type	AC
Mobile operating systems supported	Android, iOS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	239 mm
Width	160 mm
Height	157 mm
