BIXOLON Srp-275III User Manual

Rev. 1.01
- 21 -
SRP-275III
3-2-1 Memory Switch setting for Star mode
• Settings
Memory Switches are from MSW 0 to MSW 8. They are stored in non-volatile memory
(flash memory). To change the settings, send the following commands from the host.
[Name] Set Memory Switch
[Code] ASCII ESC GS # m {n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
LF NUL
Hexadecimal 1B 1D 23 m {n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
0A 00
Decimal 27 29 35 m {n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
10 0
[Defined Region] m = "W", "T", ",", "+", "-", "@"
"0" ≤ n1,n2,n3,n4 ≤ "9",
"A" ≤ n1,n2,n3,n4 ≤ "F"
[Function] Sends command to write after defining Memory Switch using the definition command specified
by the following classes to set the Memory Switch. The printer is automatically reset after writing
the setting defined by that command to the non-volatile memory.
Do not turn off the power to the printer while sending commands to the non volatile memory.
Doing so will destroy the Memory Switch setting. It is also possible for all Memory Switch settings
to become offset to their initial, default settings.
Consider the life of the non-volatile memory and avoid over-use of this command.
Function
Class
m
{n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
Data Definition (Data Specification)
Definition
","
{n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
Data definition (set specified bit)
Definition
"+"
{n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
Data definition (clear specified bit)
Definition
"-"
{n1 n2 n3 0n4}
0
... {n1 n2 n3 n4}
8
Data Definition (clear all data)
Definition
"@"
Fixed at "0000"
Definition data write and reset
Write
"W"
Fixed at "0000"
Definition data write and reset and test
print
Write
"T"
Fixed at "0000"
(Ex) Memory Switch 1-8 = 0; Memory Switch 2-7 = 1: Memory Switch 2-A =1 for a test print:
PRINT #1, CHR$(&H1B);CHR$(&H1D);CHR$(&H23);CHR$(&H2D); ' <ESC><GS> # -
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H31);CHR$(&H30);CHR$(&H30); ' 0100
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H0A);CHR$(0); ' 0000
<LF><NUL>
PRINT #1, CHR$(&H1B);CHR$(&H1D);CHR$(&H23);CHR$(&H2B); ' <ESC><GS> # +
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H34);CHR$(&H38);CHR$(&H30); ' 0480
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); ' 0000
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30); CHR$(&H0A);CHR$(0); '
0000<LF><NUL>
PRINT #1, CHR$(&H1B);CHR$(&H1D);CHR$(&H23);CHR$(&H54); ' <ESC><GS> # T
PRINT #1, CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H30);CHR$(&H0A);CHR$(&H0); ' 0000
<LF><NUL>

BIXOLON Srp-275III Specifications

General

Ethernet LAN	No
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Gray
Type	POS printer
Print speed	5.1 lps
Print technology	Dot matrix
Maximum resolution	80 x 144 DPI
Flash memory	16 MB
Internal memory	64 MB
Built-in sensors details	Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
Media thickness	0.06 - 0.085 mm
Maximum roll diameter	83 mm
Supported paper width	76.5 mm
Maximum printing width	63.5 mm
Power source type	AC
Mobile operating systems supported	Android, iOS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	239 mm
Width	160 mm
Height	157 mm
