BIXOLON Srp-275III User Manual

Rev. 1.01
- 33 -
SRP-275III
9-4 Electrical characteristics
Item
Description
Remark
SMPS Supply voltage
24VDC
Current consumption
(at 24V, except for drawer
kick-out driving)
Operating
Mean : Approximately 0.5A
Peak : Approximately 1.5A
Standby
Mean: Approximately 0.3A
NOTES
Maximum 1A for drawer kick-out driving.
9-5 Reliability
Item
Description
Remark
Life firing frequency
Mechanism : Approx. 18 million lines
Auto cutter : Approx. 1.5 million cuts
(End of life is defined as the point at which the printer reaches
the beginning of the Wear out Period.)
Head
Approx. 300 million dots/wire
9-6 Environment conditions
Item
Description
Remark
Temperature
Operating : 0~40℃ (32~104℉)
Storage : -20~60℃ (-4~140℉)
Relative humidity
Operating : 10~80% RH (Non-condensing)
Storage : 10~90% RH (Non-condensing)
NOTES
This equipment is indooruse and all the communication hiring are limited to inside of the
building.

BIXOLON Srp-275III Specifications

General

Ethernet LAN	No
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Gray
Type	POS printer
Print speed	5.1 lps
Print technology	Dot matrix
Maximum resolution	80 x 144 DPI
Flash memory	16 MB
Internal memory	64 MB
Built-in sensors details	Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
Media thickness	0.06 - 0.085 mm
Maximum roll diameter	83 mm
Supported paper width	76.5 mm
Maximum printing width	63.5 mm
Power source type	AC
Mobile operating systems supported	Android, iOS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	239 mm
Width	160 mm
Height	157 mm
