BIXOLON Srp-275III User Manual

Rev. 1.01
- 7 -
SRP-275III
■ Table of Contents
1. Setting Up the Printer ····················································································· 8
1-1 Unpacking ···························································································· 8
1-2 Choosing a place for the printer ································································ 8
1-3 Using the operation panel ········································································ 9
2. Connecting the cables·················································································· 10
2-1 Connecting the AC Adaptor···································································· 10
2-2 Connecting the Interface cable and Drawer kick-out cable ··························· 10
2-2-1 Serial Interface (RS-232C) + Ethernet + USB : OES Model ····················· 11
2-2-2 Parallel Interface (IEEE1284) + USB : OP Model ·································· 12
2-2-3 Serial Interface (RS-232C) + USB : OS Model ······································ 13
2-2-4 Drawer kick-out ·············································································· 14
3. Setting the Switches ···················································································· 15
3-1 Setting the DIP Switch ·········································································· 15
3-1-1 DIP Switch setting for Citizen(iDP 3550) mode ····································· 16
3-1-2 DIP Switch setting for Star(SP500) mode ············································· 17
3-1-3 Changing the DIP Switch setting ························································ 18
3-2 Setting the Memory Switches ································································· 19
3-2-1 Memory Switch setting for Star mode ·················································· 21
4. Ribbon Cassette Installation ········································································· 27
5. Roll Paper Installation ·················································································· 28
6. Installing the wall mount (Option) ·································································· 29
7. Self Test ····································································································· 30
8. Hexadecimal Dumping ················································································· 31
9. Specification ······························································································· 32
9-1 Printing specification ············································································· 32
9-2 Paper specifications ············································································· 32
9-3 Ribbon cassette specification ································································· 32
9-4 Electrical characteristics ········································································ 33
9-5 Reliability ··························································································· 33
9-6 Environment conditions ········································································· 33
9-7 Dimensions & weight ············································································ 34
9-8 Optional features ················································································· 35
10. Appendix - Troubleshooting ········································································ 36
10-1 ERROR LED blinking pattern ································································ 36
10-2 The printer does not start printing ·························································· 37
10-3 The printer stops printing ····································································· 38
10-4 You want to check the operation of the printer by itself ······························ 38
10-5 Printing is poor··················································································· 38

BIXOLON Srp-275III Specifications

General

Ethernet LAN	No
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Gray
Type	POS printer
Print speed	5.1 lps
Print technology	Dot matrix
Maximum resolution	80 x 144 DPI
Flash memory	16 MB
Internal memory	64 MB
Built-in sensors details	Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
Media thickness	0.06 - 0.085 mm
Maximum roll diameter	83 mm
Supported paper width	76.5 mm
Maximum printing width	63.5 mm
Power source type	AC
Mobile operating systems supported	Android, iOS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	239 mm
Width	160 mm
Height	157 mm
