BK Precision 1687B User Manual

28
Command code &
Return value
Function Example
Input command:
GETD[CR]
Return value:
[voltage][current][stat
us][CR]
OK[CR]
Get display voltage,
current, and status
reading from power
supply
[voltage] = 0000-XXXX
[current] = 0000-XXXX
[status] = 0|1 (0=CV,
1=CC)
Input command:
GETD[CR]
Return value:
030201450
OK
Indicates voltage reading is 3.02
V and current reading is 1.45 A.
Power supply is in CV mode
Input command:
GETM[CR]
Return value:
[preset 1 voltage]
[preset 1 current][CR]
[preset 2
voltage][preset 2
current][CR]
[preset 3
voltage][preset 3
current][CR]
OK[CR]
Get preset memory
values
<preset 1|2|3
voltage> = 000-XXX
<preset 1|2|3
current> = 000-XXX
Input command:
GETM[CR]
Return value:
015015
025025
035035
OK
Indicates preset 1 voltage and
current is 1.5 V and 1.5 A, preset
2 voltage and current is 2.5 V
and 2.5 A, preset 3 voltage and
current is 3.5 V and 3.5 A
Input command:
RUNM{<memory>}[CR
]
Return value:
OK[CR]
Set voltage and
current using values
saved in preset
memory locations
<memory>=0|1|2
0 = preset 1 values
1 = preset 2 values
2 = preset 3 values
Input command:
RUNM0[CR]
Return value:
OK[CR]
Sets voltage and current using
values from memory location 1
