17
Step1. Power on the Power Supply
Step2. Press the
▲ and ▼ keys to change the value
Solution 2:
Step1. Power on the instrument
Step2. Press key.
Step3. Use the numeric keys to or
▲ and ▼ keys to change the voltage value.
Step4. Press to confirm the value
3.3 Constant Current Operation
The constant current output range is from 0A to the maximum current value of each type. It is very easy
for you to set the constant current output.
Step1. Power on the Power Supply
Step2. Press key
Step3. Use the numeric keys to or use
▲and ▼keys to change the current value
Step4. Press key to confirm the value
3.4 Saving and Recalling Operation
You can store up to 16 different output states in storage register locations (1 to 16). Each output state
includes Constant voltage value, Constant current value and Maximum output voltage value. When
shipped from factory, storage locations “1” through “16” are empty. You can recall the saved settings by
Recall function.
Step1. After you setting an output state (CV value, CC value and Maximum voltage), press key.
Step2.Use the numeric keys to or
▲ and ▼ keys to select the memory location (the range
is 1 to 16) which you want to store in.
Step3. Press to confirm the memory location.
Step4. Press key.
Step5. Use numeric keys to or
▲ and ▼ keys to select the states which you want to
recall.
Step6. Press key to confirm. Then the saved settings will come on.
3.5 Menu Operation
Set Maximum voltage(>MAX VOLT）
Please be well known that the Max voltage value should be in the range of each type of Power
1. If the function keys were locked by password, you need to enter the correct
password after you press function keys (V-set, I-set, Save, Recall and Menu), then
you can do the settings.
2. If you want to cancel a function operation (V-set, I-set, Save, Recall or Menu), just
press key to exit.
