BK Precision 1785B User Manual

5
The Front Panel at a Glance
① 10 digits VFD display
② Status information for operating mode and working status
③ Power switch
④ Number keys
⑤ Function keys
⑥ UP/DOWN and ENTER key
⑦ Output terminals
Function keys description
Set the output voltage value
Set the current value
Save the present settings to a specified register location(1~16)
Recall a saved settings from location ‘‘1’’through ‘‘16’
Menu function to set related parameters of the power supply
Output ON/OFF, to enable/disable the output
V-set
I-set
Save
Menu
Recall
Out on/off
