31
1
2
3
4
5 6 7 8
9
10
11
1
2
3
4
5 6 7 8
9
10
11
Configure the software operation environments.
Voltage chart, it can show you a chart of the voltage.
Current chart: it can show you a chart of the current.
To set the remote mode of power supply.
To set the output state ON/OFF
To enable the local numeric key ⑦，it means that if you select “Enable” on this button, when the
power supply is under remote control mode, you can press numeric key ⑦ to change the control
mode to front panel control mode.
Annunciators display.
Status bar, it can show you the power supply model, communication status and operation status.
To set current value, use the rotary knob to set the current value, the setup value and
measurement value will be displayed.
To make a program of voltage and current values for the power supply, or to set the output value
quickly.
Using the rotary knob to set the voltage value, the setup value and present value will be displayed
in the 2 indicators.
