Lvl Menu item Function
4 REPEAT List is repeatedly executed after the trigger is received.
3 VOLTAGE LIST
4 ONCE List is executed once per trigger.
4 REPEAT List is repeatedly executed after the trigger is received.
3 POWER LIST
4 ONCE List is executed once per trigger.
4 REPEAT List is repeatedly executed after the trigger is received.
3 RESISTANCE LIST
4 ONCE List is executed once per trigger.
4 REPEAT List is repeatedly executed after the trigger is received.
2 CALL TEST FILE Recalls a stored test file (see Test files section).
3 RECALL N N is file number.
2 EDIT TEST FILE See Test files section for more details.
2 LIST STORE MODE
Set how the nonvolatile memory is partitioned to store
lists. You can choose between numerous short lists or
fewer longer lists.
3 8 X 120 STEPS
3 4 X 250 STEPS
3 2 X 500 STEPS
3 1 X 1000 STEPS
2 EXIT Return to prior menu level.
1 LOAD ON TIMER Enable a timed load.
2 TIMER STATE
3 ON
When the load timer is enabled by this menu element,
the load is turned on when the On/Off key is pressed.
After the set time period has elapsed, the load is turned
off.
3
OFF
When the load is turned on via the On/Off key, the load
stays ON indefinitely.
2 TIMER SET
Set the time period from 1 to 60000 s for the load to be
on.
2 EXIT Return to prior menu level.
1 EXIT Return to standard display.
8500 DC Load Series Version: February 4, 2009 Page 14 of 76
