BK Precision 8500 - Specifications - Models 8510-8526; Input Ratings and Characteristics (8510-8526); Common Characteristics for All Models; Environmental Conditions

Models 8520/8522/8524/8526 (2400W & 5000W)
Parameter 8520 8522 8524 8526
Input rating
Voltage 0 – 120 V 0 – 500 V 0 – 60 V 0 – 500 V
Current 0 – 240 A 0 – 120 A 0 – 240 A 0 – 120 A
Power 2400 W 5000 W
8520/8522/8524/8526 common characteristics
Parameter
Range
8520 8522 8524 8526
Accuracy Resolution
CV Mode
Regulation
0.1-18 V ±(0.05%+0.02% FS) 1 mV
0.1 V to Vmax ±(0.05%+0.025% FS) 10 mV
CC Mode
Regulation
0-24 A 0-12 A 0-24 A 0-12 A ±(0.1%+0.1% FS) 1 mA
0 – max Current ±(0.2%+0.15% FS) 10 mA
Current Measurement
0-12 A 0-3 A 0-24 A 0-12 A ±(0.1% + 0.1% FS) 1 mA
0 – max. Current ±(0.2%+0.15% FS) 10 mA
Voltage Measurement
0 – 18 V
8522/8526:
(0.02% + 0.02% FS)
8520/8524:
(0.02% + 0.025% FS)
1 mV
0 - Vmax ±(0.02% + 0.025%FS) 10 mV
All DC load models
common characteristics for all DC load models
Parameter Range Accuracy Resolution
CR Mode Regulation
Input current ≥FS 10%
Input Voltage≥FS 10%
0.1 -10 Ω ±(1%+0.3% FS) 0.001 Ω
10-99 Ω ±(1%+0.3% FS) 0.01 Ω
100-999 Ω ±(1%+0.3% FS) 0. 1 Ω
1K-4 KΩ ±(1%+0.8% FS) 1 Ω
CW Mode Regulation
Input current ≥FS 10%
Input Voltage≥FS 10%
0-100 W ±(1%+0.1% FS) 1 mW
100 W – max Power ±(1%+0.1% FS) 100 mW
Power Measurement
Input current ≥ FS 10%
Input Voltage ≥ FS 10%
0-100 W ±(1%+0.1% FS) 1 mW
100-max Power ±(1%+0.1% FS) 100 mW
Battery testing function
Input=0.1 V – 120 V Max measurement capacity= 999 A/H
Resolution =10 mA Timer range=1~60000 sec
Transition Mode
Range of Frequency 0.1 Hz-1 kHz Frequency error rate＜0.5%
NOTE: Specifications and information are subject to change without notice. Please visit
www.bkprecision.com for the most current product information.
Environmental Conditions
This instrument is intended for indoor use in a pollution degree 2 environment. Operating
environmental limits are as follows:
8500 DC Load Series Version: February 4, 2009 Page 16 of 76
